Enduro bearings – XD15 Ceramic. RODAMIENTO HÍBRIDO | Hybrid Bearing. CXD-6902-LLB. 15mm x 28mm x 7mm
112,38€ iva inc.
4 disponibles
# PRODUCTO BAJO PEDIDO: info@rmgwheels.com
# ON REQUEST ITEM: info@rmgwheels.com
Descripción |
Description
Enduro bearings – XD15 Ceramic. RODAMIENTO HÍBRIDO | Hybrid Bearing. CXD-6902-LLB. 15mm x 28mm x 7mm
# PRODUCTO BAJO PEDIDO: info@rmgwheels.com
# ON REQUEST ITEM: info@rmgwheels.com
Ø Int.: 15mm
Ø Ext.: 28mm
I—I : 7mm
Rodamiento de Bolas Radial Híbrido Cerámico serie XD-15
· Para Movimiento: GIRATORIO. (Bujes, Pedalieres, Roldanas, Pedales, etc)
· Material de Pistas: XD-15. Acero Inozidable especial enfriado y reposado en una cámara con nitrógeno para conseguir una alta homogeneidad y pureza libre de carburos, que le confiere una excepcional resistencia a la fatiga y a la corrosión, Incluso operando con arena en su interior, no se desgastará, sino que las pistas se pulirán y suavizarán.
· Material Bolas: Cerámicas de fabricación propia. (Nitruro de silicio Si3N4 de alta densidad y pureza). 58% más ligero y 121% más duro que el acero.
· Retenedor: Nylon para baja fricción con lubricante seco impregnado (grafito). Desmontable para mantenimiento
· Tolerancia: ABEC 5
· Juego Interno: C3
· Esfericidad de Bolas: G3. (3/1.000.000")
· Obturadores: Goma NBR laberíntico ambos lados. LLB (doble labio, ligero contacto)
· Grasa: Kluber NBU52 baja viscosidad para máxima velocidad
· Pistas de bolas más profundas que los estándares de la industria para albergar unas bolas más grandes y obtener una capacidad de carga y vida del rodamiento mayores.
LLB: Obturador laberíntico de goma de nitrilo de doble labio con respaldo metálico. El labio externo mantiene el agua y contaminantes fuera, mientras que el labio interior, con una ligera fricción contra el anillo interior del rodamiento, mantiene la grasa dentro, creando además una barrera de protección de grasa.
Recomendamos relubricar con la grasa original especial (click aquí) para evitar que con el uso prolongado pueda funcionar sin lubricación y las bolas cerámicas (más duras) desgasten las pistas de acero. Con un mantenimiento adecuado, su duración puede multiplicar varias veces la de un rodamiento de acero (y con un rendimiento mucho más alto).
GARANTÍA DE POR VIDA EN LA SERIE ENDURO BEARINGS XD-15. (LIMITADA, BAJO SUPERVISIÓN DEL PRODUCTO POR LA MARCA)
XD-15 series Ceramic Hybrid Radial Ball Bearing
· For Movement: SPINNING. (Hubs, BB´s, Jockey Wheels, Pedals, etc)
· Rings Material: XD-15. The ultimate bearing race material. It´s a very special stainless steel, made by re-melting it in a special chamber where nitrogen gas is introduced during the infusion process for an extremely high uniform and pure steel, free of carbides, to achieve an ultimate level of fatigue and corrosion resistance, at a point that if dust or sand would get inside it will even smooth races by polishing them.
· Balls Material: Propietary Ceramic (High density and purity Silicon nitride Si3N4). 58% lighter and 121% harder than steel.
· Retainer: Clip-in Nylon with infused graphite (dry lubricant). Removable for maintenance
· Tolerance: ABEC 5
· Internal Clearance: C3
· Balls Roundness: G3. (3/1.000.000")
· Seals: NBR rubber both sides. Labyrinth. LLB (dual lip, light contact)
· Grease: Kluber NBU52 Low Viscosity High Speed
· Deeper ball races than industry standards to fit bigger balls for a higher load capacity and bearing life.
LLB: Light contact dual lip labyrinth Nitrile rubber seal. The outside lip keeps water and contaminants out, while the inner lip retains grease for smooth function and long service intervals.
We recommend relubricating with the special original grease (click here) in order to avoid ceramic balls (harder than steel) coud wear the ring races by a long term operation without lubricant.
LIFETIME WARRANTY ON ENDURO BEARINGS XD-15 SERIES (LIMITED BY MANUFACTURER´S INSPECTION OF THE ITEM)
